General Information

Manufacturer: Crown Equipment Corporation
Series: FC 4500 Series
Truck Type: Sit down rider, 4 wheel electric counterbalance
Power Type: Electric (36V or 48V)
Operator Type: Sit down, counterbalanced
Capacity & Performance

Rated Load Capacity: 4,000 lb (1,815 kg)
Load Center: 24 in (600 mm)
Travel Speed (Empty / Loaded):
48V: 11.0 / 10.2 mph
36V: 9.0 / 8.3 mph
Lift Speed (Empty / Loaded):
Up to 110 / 92 fpm (48V, AC)
Up to 104 / 71 fpm (36V, AC)
Gradeability (Loaded): Up to 35–38% (model dependent)
Dimensions

Headlength (to fork face): 77.8 – 84 in
Overall Width:
Standard tread: 43.4 in
Wide tread: 47.5 in
Turning Radius: 69.1 – 75.3 in
Aisle Width (Rightangle stack): 84.9 – 91.1 in
Wheelbase: 49.7 – 54.7 in
Mast & Forks

Maximum Lift Height (MFH): Up to 188 in (varies by mast)
Free Lift Height: Up to 32.2 in
Tilt Angle (F/B): 5° / 5°
Fork Carriage: ITA Class II
Standard Fork Size: 36 × 4 × 1.8 in
Optional Fork Lengths: 42, 48, 54, 60 in
Tires & Chassis

Tire Type: Cushion
Front Tires: 21 × 7 × 15 in
Rear Tires: 16 × 6 × 10.5 in
Ground Clearance (Loaded):
Lowest point: 3.0 in
Center of wheelbase: 4.8 in
Weight

Truck Weight (Less Battery): ~7,195 – 7,243 lb
Axle Load (Loaded, with max battery):
Front: up to 11,987 lb
Rear: up to 2,242 lb
Battery & Electrical

Battery Type: Leadacid
Battery Voltage: 36V or 48V
Battery Capacity:
36V: up to 1,430 Ah
48V: up to 1,100 Ah
Battery Weight: 2,630 – 4,000 lb
Brakes

Service Brake: Footoperated hydraulic
