WJ60-485 8-Channel DI/DO Digital Signal Converter WAYJUN – Industrial I/O Module – Supplier

Features：                                                                       >> Eight channels digital signal input and output>> Input/output/power supply:non-isolation>> Over voltage protection,reverse polarity protection>> Can read level status of each channel via the RS-485/232 interface>> Wide power supply range: 8 ~ 32VDC>> High reliability, easy programming, easy application>> DIN35 Rail-mounted>> Can programme setting module address,baud rate>> Support Modbus RTU communication protocol>> Dimensions: 120 mm x 70 mm x 43mmProduct Overview:     WAYJUN WJ60 series products realize the signal acquisition between sensor and host, to measure the switching signal. WJ60 series can be used in RS-232/485 bus industrial automation control system, switching signal measurement,monitoring and control, high and low level signal measurement, industrial field signal isolation and long-term industrial transmission and so on.WJ61 General parameters:(typical @ +25 ℃, Vs is 24VDC)Input type: switch input(DI0~DI7)Low level: input <1VHigh level: input 3.5~30VInput Resistance:>10KΩOutput type: open collector output, voltage 0~30V,maximum load current:30mA,8                               channels(DO0~DO7)Communication: RS-485 protocol or RS-232 standard characters protocols and                                          MODBUS RTU communication protocolBaud Rate (2400,4800,9600,19200,38400 bps) can be selected via softwareAddress (0 to 255) can be selected via softwareCommunication Response Time: 100 ms maximumPower Supply: +8 ~ 32VDC wide range power supply, internal anti-reverse and over-                              voltage protection circuitPower Loss: less than 0.5WOperating Temperature: - 45 ~ +85℃Humidity: 10 ~ 90% (no condensation)Storage Temperature: - 45 ~ +85℃Storage Humidity: 10 ~ 95% (no condensation)Isolation Voltage: non-isolationDimensions: 120 mm x 70 mm x 43mm

Digital signal input types:1.Dry contact input2.Wet contact input3.Open collector input4.TTL / CMOS level, 24V level inputProduct Selection:Type No.: WJ60-485 (input:8-ch digital signal,output:485 interface)Type No.: WJ60-232 (input:8-ch digital signal,output:232 interface)
