DN-25Q / 35Q / 50Q / 63Q Pipe Fittings – Plumbing Supplies Supplier & Bulk Pricing
GET A FREE QUOTE NOW
| Model | DN-25Q | DN-35Q | DN-50Q | DN-63Q | ||
| Primary Voltage(V) | 380 | 380 | 380 | 380 | ||
| Rated Input Capacity(KVA) | 25 | 35 | 50 | 63 | ||
| Rated Input Current(A) | 66 | 92 | 132 | 166 | ||
| Rated Duty Cycle(%) | 20 | 20 | 20 | 20 | ||
| Secondary Voltage Adjust Step | — | — | — | — | ||
| Secondary No-load Voltage(V) | 0.5-3.52 | 0.5-4.3 | 0.5-5 | 0.5-6.7 | ||
| Electrode Arm Extension Length(mm) | 350 | 350 | 350 | 350 | ||
| Horn Spacing(mm) | 220 | 220 | 220 | 220 | ||
| Upper Electrode Working Stroke(mm) | 25-100 | 25-100 | 25-100 | 25-100 | ||
| Max.Electrode Force(N) | 4000 | 4000 | 4000 | 4000 | ||
| Electrode Size(mm) | Electrode Arm | Ф55 | Ф55 | Ф55 | Ф55 | |
| Electrode Holder | Ф25 | Ф25 | Ф25 | Ф25 | ||
| Welding Thickness(mm) | Low Carbon Steel | 2+2 | 2.5+2.5 | 3+3 | 3.5+3.5 | |
| Stainless Steel | 0.8+0.8 | 0.9+0.9 | 1+1 | 1.2+1.2 | ||
| Compressed Air Pressure（mpr） | 0.6 | 0.6 | 0.6 | 0.6 | ||
| Consumption Of Compressed Air（M3/h） | 12 | 12 | 12 | 12 | ||
| Flow Of Cooling Water（L/min） | 6 | 6 | 6 | 6 | ||
| Dimensions(mm) | 1030x400x1760 | 1030x400x1760 | 1030x400x1760 | 1030x400x1760 | ||
| Weight（KG） | 250 | 260 | 280 | 300 | ||
| Suggest Input Wire Cross-sectional Area(mm2) | 8 | 10 | 10 | 16 | ||
