Woodworking CNC Band Saw Machine for Curved Line Wood Processing (MJS 1612B) – Custom Wood Cutting Equipment

1,  Machining method: Workpiece movement and saw blade rotation
2,  Working size:  2500×1250×200mm
3,  Material Clamps:  4 pieces in total
4,  Press Method:  Roller Press×2(D76×1150mm)
5,  Movable Aluminum Alloy Bar  5 pcs
6,  X-axis drive method:  Precision rack and pinion
7,  Y-axis drive method :  Precision ball screw
8,  Maximum working feed:  1~25m/min
9,  Maximum return feed:  50m/min
10,Dimension of saw blade: L 5040×W 12~1mm×T 0.7mm
11,Saw blade tensioning method: Air pressure tension
12,Saw wheel tensioning cylinder:  D125×50
13,Cylinder tension pressure:  0.4Mpa
14,Saw wheel diameter:  800×40mm
15,Saw wheel rotation:   450~700rpm
16,Minimum cutting radius of the arc: 30mm
17,Saw blade turning angle: ±90°
18,Power of main motor:  11kw
19,X-axis servo motor power : 2.0kw
20,Y-axis servo motor power : 1.0kw
21,Z-axis servo motor power : 0.4kw×2
22,  Worktable feed linear guide: 30
23,  Control System:  CNC
24,  Overall dimension :
Saw  (L×W×H)   1000×665×2325mm
Worktable(L×W×H) 5300×2100×1660mm
Electric control box(L×W×H) 1250×600×1600mm
